Designed for public and commercial spaces, this charger combines durability with efficiency to keep vehicles moving and customers satisfied. Built to handle frequent use, it delivers reliable performance day after day.
With secure access options and a design ready for heavy duty environments,
it’s the perfect solution for workplaces, fleets, car parks and service stations.
Easy to manage and built to last, it supports your business while driving the
future of mobility.
Technical Specifications
Model:
AJEU-AC04-44KCC-Excalibur
Input Power:
380~415V, Max. 32A, Three Phase
Output Power:
22kW + 22kW
Connection Options:
Socket type
Charging Standard:
IEC62196-2 Type 2
Chage Scheduling:
Dynamic Load Management (DLB)
Energy Consumption Report:
Two MID meters
Remote Software Updates:
OTA update, OCPP1.6J (Upgradeable to 2.0), Web portal or App
Environmentally Friendly:
Metal enclosure, NEMA Type 3, Designed for indoor/outdoor use
International Standards Compliance:
IEC61851-1 & -22, IEC62196, IEC61008-1,
IEC62955
User-Friendly:
5"LCD (800×480 pixel), LED status indication, RFID/QR code/APP
authentication, Ethernet/Wi-Fi/4G/RS485, POS terminal, floor-mounted design
Cable Length:
Output 7m
Other Details
24/7 Customer Support:
✓
2-Year Warranty | Support available after warranty:
